WEINTEK ® HMI MT8053 IE

  • Wide input voltage range : 10,5 ~ 28VDC
  • 4.3″ 480×272 TFT LCD, LED Backlight
  • Slim design
  • Fan-less Cooling System
  • 2 Ethernet ports
  • COM1 and COM3 RS-485 2W support MPI 187.5K, please use one at one time
  • PCB coating process ensures high reliability to resist from corrosive
    in harsh environment
  • Built-in Power Isolator
  • Buil-in EasyAcess 2.0 License
  • NEMA4/IP65 Compliant Front Panel























Dual-Ethernet-port ensures that MT8053iE can be on two independent networks, whereby one port connects to the controller, and the other one connects to the host computer or is used for remote control (e.g.: built-in EasyAccess 2.0). Not only will the separation of networks effectively avoid the possibility of network interference and congestion, but it will also greatly improve the reliability and stability of data transfer, leaving out security concerns.

















MT8053iE Features

  •  High Performance : 32-bit RISC 600MHz CPU and 16.7M colors display.
  • Rich I/O : Dual-Ethernet, USB Host 2.0, Serial Ports COM1: RS-232/RS-4852W/4W COM3: RS-485 2W.
  • High Reliability : Industrial level protections: PCB coating and power isolation
  • Wide Input Voltage Range : 10.5~28VDC wide voltage range input for installation in varied power conditions.
  • Powerful Connectivity : Supports more than 300 drivers, most of which are for major brands of PLCs and controllers.
  • Remote Access Service, EasyAccess 2.0 : The EasyAccess 2.0 license is included; therefore, activation using an activation card is not necessary.
  • IIoT Protocol Support : Supports MQTT and MODBUS TCP/IP Gateway, making it convenient to access data for upper layer devices.
  • Applicable software version: EasyBuilder Pro V6.02.01 or later
